Advantages
◎ With electronic chemical leveling and brightening effect, the surface roughness value can reach Ra0.05 (v12),
and the reflectivity can reach more than 90%.
◎ Prevent the phenomenon of hanging materials and sticking on the surface of the equipment.
◎Metal surface can achieve good passivation effect.
◎ Uniform and dense chromium salt film is formed on the surface, which greatly improves the resistance to
environmental corrosion.
Main Technical Parameters
|
Model
|
JSEL-54
|
|
Function
|
Electrochemical leveling and polishing
|
|
Technology
|
Electrolytic
|
|
Working station
|
10
|
|
Output
|
4000-6000pcs/8h
|
|
Voltage
|
380V~/415V~
|
|
High frequency switching power supply
|
3000A/18V
|
|
Power
|
54kW
|
|
Size
|
2200*720*750mm
|
|
Weight
|
350kg
|
|
Conductive copper
tube
|
32*4*2500mm*3
|
|
Positive&negative conductive copper plates
|
1
|
|
Heat pipe
|
1
|
|
Anode Conductive Plate
|
3*180*610mm*20
|
|
Copper conductive hanger
|
10
|
