Advantages
◎ This machine is suitable for cleaning after the brazing process to protect the aluminum mezzanine at the
bottom of the brazing process.
◎ Clean the surface of the product by heating and spraying, dust removal, oil removal and wax removal.
◎ Applicable to products of various diameters, applicable to a wide range of products
◎ Channel cleaning, only loading and unloading, automatic cleaning and drying, reducing labor.
Processing
Loading →unoil(50-60℃)→ cold washing 1 → cold washing 2→ tap water/pure water rinsing →
hot washing →blow water → drying(120℃) → download
Main Technical Parameters
|
Model
|
JSB-W-300
|
|
Function
|
Remove oil,
fluid & dust
|
|
Technology
|
Physical cleaning
|
|
Work Piece
Material
|
Stainless steel
|
|
Standard Work
piece
|
Φ280*140mm(H)
|
|
Work piece
Pitch
|
300mm each row of three
|
|
Standard work
piece production
|
400pcs/h
|
|
Speed
|
700mm/min(0.5-2m/min adjustable frequency)
|
|
Energy
|
Liquefied natural gas, electricity
|
|
This cleaning line can customized according to customer's product size and capacity needed
|
